PCB Materials / Substrates

P.W. Circuits hold stock of a wide range of PCB materials ranging from basic FR4 to a polyimide & ceramic flexi-rigid. If we don’t have it in stock then we have an excellent network of suppliers so you don’t have to wait any longer than you need to when ordering a PCB (Printed Circuit Board).

For more information click the links below to take you to the relevant data page or contact a member of our sales team regarding PCB substrates or any other element of UK PCB manufacturer, design or assembly of circuit boards. Check our YouTube channel too for more PCB related information.

Range of Substrates

FR4 PCB substrate(Isola, Nelco, Panasonic, Ventec, Kingboard etc)
High TG FR4 PCB substrates(Isola, Nelco, Panasonic, Ventec, Kingboard etc)
Polyimide PCB substrates(Isola, Nelco, Ventec etc)
PTFE(Rogers, Arlon, Taconic etc)
Ceramic PCB substrates(96% / 99.6% Alumina, Al2O3, HPS, Si3N4, AlN etc)
Liquid Crystal Polymers(Rogers, Arlon)
Aramid(Arlon, Taconic)
Rogers substrates(RO3000, RO4000, Duroid, Ultralam, Kappa etc)
Arlon Substrates(AD Series,TC Series, Diclad, Cuclad, Isoclad etc)
Taconic substrates(RF, TLY, TLC, TLX, TFR etc)
Metal backed PCB’s(Aluminium, Copper, Brass, IMS)
Ohmegaply
Foam printed circuit boards(Rohacell, Airex etc)
Flexible Material Polyimide & Polyester Film ED/RA (DuPont, Espanex, GTS etc)

Why are there different PCB materials?

  • Material Properties: Different electronic applications require PCBs with specific properties. For example, some applications might need a material that’s very good at conducting heat (thermal management), while others might need a material that’s incredibly strong and rigid (structural support). Different substates cater to these varying needs by using materials with specific properties like:
    • Dielectric constant: This affects how well the material transmits electrical signals.
    • Thermal conductivity: This affects how well the material conducts heat.
    • Coefficient of thermal expansion (CTE): This affects how much the material expands or contracts with temperature changes.
    • Mechanical strength: This affects how much weight and stress the material can handle.
  • Functionality: PCBs can have different layers with varying functionalities. Some substates might be specifically designed for signal layers, while others might be better suited for power planes or ground planes.
    • Signal layers: These carry electrical signals between components. They require materials with good electrical conductivity and controlled dielectric constant.
    • Power planes and ground planes: These provide stable voltage levels and help manage heat. They might use different materials than signal layers for better current handling or heat dissipation.
  • Manufacturing Considerations: Some substates are easier or more cost-effective to manufacture than others. This can be a factor depending on the complexity of the PCB design and the desired production volume.
  • Environmental Regulations: Certain applications, especially those in sensitive environments, might have regulations regarding the materials used in PCBs. Some substates might comply with these regulations better than others.

In short, different PCB substates exist to provide a variety of options for designers depending on the specific needs of their electronic device.
